If you have never had to install a grab bar in a bathroom, the process of deciding where to place one can be intimidating.

You decided you need a shower grab bar, or a toilet grab bar or a bathroom grab bar. Maybe to help with stabilization during visits to the bathroom.

But where do you put the grab bars so that you maximize their usefulness for the person in need of help?

Don’t worry. There’s only two simple considerations that you need to figure out where to put your new grab bars and I’ll show you.

This post will highlight the strategies and supplies needed to help prepare the space for grab bar placement. If you would prefer to view a video about this topic please review this video on my YouTube Channel EquipMeOT.

Supplies Needed:

Planning
Shower
Toilet
- If You Cannot Access a Wall Stud

Grab Bar Placement: Planning

Grab bar placement requires two important considerations:

WHO is using the grab bar
HOW the bathroom is constructed and where will a grab bar be safely positioned.

Understanding who will be using these grab bars will be vital in positioning them for maximizing value. What are their limitations? How will they be using the bathrooms? What are their physical attributes (height, weight, etc.)?

Understanding how the bathroom is constructed, where studs are located, types of materials used for shower surrounds, and the space available will drive the remainder of your decisions for grab bar placement.

Let’s keep these considerations in mind while we evaluate the two most popular places in the bathroom for grab bars: the shower and the toilet.

First up, the shower.

Grab Bar Placement: Shower

When evaluating a shower for grab bar placement, I start by assessing the layout of the shower. Where are the users stepping in and out, what type of surround (tile or plastic/fiberglass), and general wall stud location. The layout of the shower will guide the type of grab bar I select and where, realistically, I could place them.

For New Construction or Remodeling

If you are fortunate enough to be completing this task during the construction process, the grab bar placement can be configured before closing the walls by placing solid wood boards between studs where grab bars will be mounted. This is a wonderful option whether you plan to install the grab bars immediately or just want the option in the future. Plan ahead and save yourself a ton of time!

Shower Grab Bar Placement Recommendations

The standard grab bar placement recommendation is for 3 bars to be placed in the shower.

One vertically at the exterior entrance of the shower
One horizontally at the inside wall
One vertically underneath the shower head.

Shower Grab Bar Placement - All Three Positions Marked with Painter's Tape — You can see we marked the 3 recommended positions in this shower with blue painter’s tape

I use painter’s tape to mark the exact location that my user tends to reach for when completing their transfers. It is best to have the person present and able to simulate their transfer when completing the assessment. I like to select a longer grab bar (18″+) versus short for all positions.

Positioning a grab bar vertically is the most flexible due to the likelihood of a stud present the entire length of the wall.

Shower Grab Bar Placement - Mark Under The Shower Head — Here, we marked a vertical position for a grab bar under the shower head

Shower Grab Bar Vertical Position Marked Outside Shower With Tape — We also marked a grab bar for a vertical position outside the shower

However, for horizontal grab bars, a minimum length of 16″ and maximum of 32″ will give you the best chance of hitting 2 studs if your wall is constructed with standard stud spacing of 16″ on center.

Lastly, we marked a grab bar for a horizontal position across the far wall. A horizontal position allows this grab bar to span two walls studs.

Shower Grab Bar Placement: Plastic or Fiberglass Surrounds

A tip for plastic and fiberglass surrounds: If you cannot locate a stud with the deep scan setting on your stud finder, locate through a shared wall if possible. Plastic and fiberglass surrounds are particularly difficult to work with due to the space present between the studs and the surround. The best options for getting your grab bar securely into a stud is to either use a spacer kit (like this one) or access the studs from the opposite wall by opening the drywall and applying a board to drill into up against the back of the surround.

Grab Bar Placement: Toilet

For toiler grab bars, I’m going to be discussing grab bars that are placed on the wall. These grab bars are in contrast to the toilet safety rails which are mounted on the toilet themselves. If you are more interested in toilet safety rails, I have a blog post and video all about how to install toilet safety rails if you would like more information.

Toilet grab bars tend to easier to install because the access to a wall stud is significantly simpler to locate through the drywall. I recommend always getting both ends of the grab bar into two studs for safety.

Use your stud finder to mark a few studs around the perimeter of the toilet with painters tape to assist with your decisions on exactly where the bars will be most useful to the users.

Toilet Grab Bar - Use stud-finder to locate wall studs for grab bar — We used a deep-scan stud-finder to ensure that our grab positions spanned two wall studs

The standard positions for grab bars around the toilet are on either or both sides and behind the tank. These positions are all recommended to be horizontal and at a height appropriate to the height of the toilet and the height of the users. I recommend using 16″ or 32″ long grab bars for this use as to ensure greatest likelihood of hitting 2 studs.

Toilet Grab Bar - Mark Position Next To Toilet on Wall — This grab bar was positioned next to the toilet on the wall.

Toilet Grab Bar Placement - Mark Position Behind Toilet — The other grab bar we marked behind the toilet

Toilet Grab Bar Placement: If You Cannot Access a Wall Stud

If, you absolutely cannot hit a wall stud with one end of your grab bar, I recommend using a secure hollow wall grab bar mounting device like this or this. These work with many types of grab bars but typically are best suited for combining with their same brand.

NOTE: These hollow wall mounting devices require a deep cavity space (2.5-3″), so check ahead before forking out for these!

That’s it!
